◆Main Material: 304 stainless steel
◆Surface Finish: Mirror-polished, Brushed, Black, Titanium Gold
◆Installation Instructions:
1. Maximum load capacity of the shower room: 150 kg
2. The maximum installation length for a 180° shower room is 1.8 m; the maximum installation length for a 90° double-door shower room is 1.0 m
3. The guide rails supplied with your order do not have pre-drilled holes; you will need to drill the holes yourself during installation
4. The fittings are only suitable for clamping 10–12 mm tempered glass.
5. When drilling holes in the glass, please strictly adhere to the dimensions shown in the installation diagram.
6. Each model can be installed as a 90° double-door, 90° single-door or 180° configuration
Glass Door Hardware
LX-8020
| tem | PRODUCT SPECIFICATIONS |
|---|---|
| Model | LX-8020 |
| Standard Height | Customizable |
| Material | Stainless Steel 304 |
| Finish | Mirror/Satin/Custom |
| Applications | Office, Meeting Room… |
| Features | Sturdy & Stable Structure, Precision Craftsmanship |
